Basic Info.
Product Description
Main Technical Parameters
- Intrinsic error: ±1%
- Return difference: 1%
- Dead zone: 0.5% ~ 10% adjustable
- Damping force characteristic: dead-beat
- Protection level: IP67 (IP68 optional )
- Environment temperature:-25ºC~ +70ºC
- Relative Humidity: <95% (without condensation )
- Power supply: 380Va.c(340V-440V), 50Hz/60Hz ЗPH
Model | D | D1 | D2 | D3 | D4 | E | F | K | H | H1 | H2 | n-Md | h | Output Torque (Nm) |
FRYQ18+BW1 | Φ328 | Φ45 | Φ125 | Φ162 | 20 | 94 | 14 | 558 | 295 | 258.5 | 4-M12 | 1000 | ||
FRYQ18+BW2 | Φ328 | Φ60 | Φ140 | Φ178 | 25 | 87 | 18 | 603 | 295 | 258.5 | 4-M16 | 1600 | ||
FRYQ18+BW3 | Φ328 | Φ70 | Φ165 | Φ210 | 25 | 95.5 | 20 | 685 | 295 | 258.5 | 4-M20 | 2500 | ||
FRYQ18+BW4 | Φ328 | Φ70 | Φ165 | Φ210 | 30 | 92 | 20 | 739 | 295 | 258.5 | 4-M20 | 4000 | ||
FRYQ25+BW5 | Φ642 | Φ70 | Φ165 | Φ218 | 25 | 103 | 2-20 | 900 | 324 | 357 | 4-M20 | 6000 | ||
FRYQ25+BW6 | Φ642 | Φ75 | Φ254 | Φ200 | 25 | 165 | 2-20 | 877 | 324 | 357 | 8-M16 | 5.5 | 8000 | |
FRYQ35+BW7 | Φ780 | Φ254 | Φ200 | 25 | 165 | 2-20 | 1102 | 338 | 357 | 8-M16 | 5.5 | 10000 | ||
FRYQ35+BW8 | Φ780 | Φ254 | Φ200 | 25 | 165 | 2-20 | 1102 | 338 | 357 | 8-M16 | 5.5 | 15000 |
Model | A1 | A2 | A3 | A4 | A5 | C | D1 | D2 | n-Φd1 | Output Torque (Nm) |
FRYQ18+BW1 | 240 | 280 | 150 | 190 | 120 | 170 | 200 | 250 | 2-Φ20 | 1000 |
FRYQ18+BW2 | 375 | 435 | 175 | 235 | 195 | 170 | 200 | 250 | 2-Φ20 | 1600 |
FRYQ18+BW3 | 500 | 560 | 180 | 240 | 210 | 230 | 200 | 250 | 2-Φ30 | 2500 |
FRYQ18+BW4 | 500 | 560 | 180 | 240 | 210 | 230 | 200 | 250 | 2-Φ30 | 4000 |
FRYQ25+BW5 | 480 | 540 | 260 | 320 | 200 | 267 | 350 | Φ36 | 6000 | |
FRYQ25+BW6 | 600 | 670 | 250 | 320 | 320 | 300 | 400 | Φ40 | 8000 | |
FRYQ35+BW7 | 600 | 670 | 250 | 320 | 320 | 300 | 400 | Φ40 | 10000 | |
FRYQ35+BW8 | 600 | 670 | 250 | 320 | 320 | 300 | 400 | Φ40 | 15000 |
Hart Communication Protocol
HART communication uses a half-duplex communication method, which is characterized by the realization of digital signal communication on the existing analog signal transmission line, which is a transitional product during the transition from analog system to digital system, so it has a strong The market competitiveness has developed rapidly. HART stipulates a series of commands, which work according to the command mode.
PROFIBUS is an international, open field bus standard that does not depend on equipment manufacturers. The transmission speed of PROFIBUS can be selected in the range of 9.6kbaud ~ 12Mbaud and when the bus system is started, all devices connected to the bus should be set to the same speed. It is widely used in manufacturing automation, process industrial automation and building, transportation and other fields of automation. PROFIBUS is a field bus technology used for factory automation workshop-level monitoring and field device layer data communication and control.
Modbus is a serial communication protocol published by Modicon (now Schneider Electric) in 1979 for communication using programmable logic controllers (PLCs). Modbus has become the industry standard for industrial communication protocols (De facto) and is now the usual connection between industrial electronic devices.
ω Visualization
ω Debugging convenient
ω Operation and monitoring functions
ω Diagnostic function
ω Diagnostic function
Q1.How about your price?
Although high quality but the price is vary favorable.
Q2. What is your MOQ?
A: 1 PC.
Q3. What is the delivery time?
A: It is about 1-7 days after we receive the payment.
Q4. How to make the payment?
A: We accept T/T, Paypal, Ali Trade Assurance,etc.
Q5. Do you have products in stock?
A: Yes, some stock can be shipped out within 3 days.
Q6. Do you test all your goods before delivery?
A: Yes, all products are fully inspected before delivery.
Q7. What is the warranty?
A: Our warranty is one year. After you receive the goods, if you find defect products, just take pics or videos to send us. We will re-make it for re-fund them to customers once we confirm it is our responsibilities.
