Basic Info.
Model NO.
HGZK
Driving Mode
Electric
Nominal Pressure
PN1.0-32.0MPa
Channel
Straight Through Type
Structure
Fixed Ball Valve
Type
Fixed Ball Valve
Function
Blow-Down Valve
Temperature
Normal Temperature
Standard
GB,ANSI,DIN,JIS,ISO,API,AISI
Application
Industrial Usage
Connection
Threaded,Flange
Warranty
12 Months
Voltage
AC220V,DC24V
Medium
Water,Gas,Oil
Valve Body
Stainless Steel
Pressure
0~25bar
Transport Package
Carton, Woodencase, Pallet
Specification
50*50*50cm
Trademark
HGZK
Origin
China
HS Code
8481100090
Production Capacity
1000set/Month
Product Description
Electric ball valve is an important actuator in industrial automation control system. The electric ball valve is a valve that rotates around the axis of the valve stem according to this movement form of the valve disc. The change of the valve seat port is proportional to the disc stroke. It is mainly used to cut off or connect the medium in the pipeline, and can also be used for the regulation and control of the fluid. It is a pipeline pressure component for industrial automation process control.
| Product Name | Electric Ball Valve |
| Voltage | DC12V,DC24V,AC24V,AC110V,AC220V,AC380V |
| Connection | threaded,flange,clamp |
| Valve body | 304, 316, 316L,plastic |
| Valve seat | PTFE, PPL, metal |
| Type | On/Off, Regulation, Intelligent |
| Output torque | 50~4000Nm |
| Rotation angle | 0-90° ± 3° |
| Action time | 15S/30S/60S |
| Ambient Temp | -20°C ~ +60°C |
| Color | white, blue, customized |
1. Can you do OEM for me?
We accept all OEM/ODM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you asap.
2. What's your terms of payment?
T/T, L/C , Alibaba Trade Assurance available, full protection for your orders.
3. Do you have more valve products?
We produce various valves.Pneumatic valves, electric valves,ball valves, butterfly valves are our main products.Contact us for catalogue.
4. Why choose Us?
Factory direct sale;Strong production capacity;Competitive price;Strict quality control;Quality assurance;Perfect after-sales service.
5. How to proceed an order for your product?
Provide your request. We will quote according to your requirements.Confirm the product and deposit for the formal order.We arrange production.
