Basic Info.
Model NO.
A-Series(Stainless Steel)
Output Torque
8Nm~2128Nm
Working Temperature
-40~+80/-20~+80/-20~+150
Action Type
Double Acting/Single Acting
Color
Steel
Stainless Steel Grade
304/316
Stroke Type
Rotary
Conection Type
G/NPT
Shaft Hole Type
Double Square/Double D/Keyway
Air Pressure
2bar~8bar
Supplier Type
Manufacturer/Factory
Transport Package
Carton or Wooden Box
Specification
CE, ATEX, SIL, ISO9001
Trademark
ALPHA
Origin
Wuxi Jiangsu China
HS Code
84123900
Production Capacity
300000 PCS/Year
Product Description
A(Stainless Steel)-Series Pneumatic Actuator
Cylinder
Ø 52, Ø 63, Ø 83, Ø 105, Ø 125, Ø 140, Ø 160, Ø 210
Output Torque
Product Catalog
(1)Specification
(2)Material & Construction
(3)Torque
(4)Certification
(5)Company Profile
(6)Working Condition
Contact us!
Steve
WUXI ST.HANS PNEUMATIC VALVE ACTUATOR MARKER CO.,LTD
Add:No.48,Xihong Rd,Meicun Industrial Park,Xinwu District,Wuxi City,Jiangsu Province,China
- 316L, 316, 304, and 303 stainless steel actuators have an electrolytic polished appearance, which is smooth and beautiful, and has strong corrosion resistance. They are suitable for engineering environments with high corrosion resistance requirements.
- Double piston rack and pinion design, compact structure, symmetrical installation position, easy to change output shaft rotation, long service life, and rapid action.
- The back of the piston rack is equipped with composite bearings and guide rings, which provide accurate movement, small friction coefficient, and extended service life.
- Combined pre loaded plated spring with long service life and strong corrosion resistance.
- High precision gear and rack, small meshing clearance, high accuracy, and large output power.
- Stainless steel fasteners, safe and beautiful, strong corrosion resistance.
- Dimensions according to international specifications:
- Output shaft groove and screw hole; The size of the top mounting hole meets the NAMUR standard;
- The size of the air source interface meets the NAMUR standard;
- The size of the bottom mounting hole complies with ISO5211 and DIN3337 standards,
- Convenient to install accessories such as solenoid valve limit switches.
- Operating Media: Dry or lubricated air, or inert/non-corrosive gas, impurity particles in media less than 30um.
- Aupply Pressure: 2 bar ~ 8 bar
- Installation: Both suitable for indoor and outdoor.
- Working Temperature:
Standard:(-20°C ~ +80°C)
High temperature:(-20°C ~ +150°C)
Low temperature:(-40°C ~ +80°C)
Cylinder
Ø 52, Ø 63, Ø 83, Ø 105, Ø 125, Ø 140, Ø 160, Ø 210
Output Torque
| Action Type | Minimum Torque | Maximum Torque |
| Double Acting(DA) | 8Nm | 2128Nm |
| Single Acting(SR) | 4.3Nm | 660Nm |
