PRODUCT NAME | Pneumatic diaphragm actuator. |
Suitable Temp. | -10ºC-60ºC |
Working Temp. | ≤0.35MPa |
Working Medium | Cleaned compressed air |
Working Manner | Air to close /Air to open |
Product description
Brief introduction to pneumatic diaphragm actuator
SAZR type multi spring pneumatic actuator is a new type of pneumatic actuator, which is designed and developed for the new type of pneumatic actuator, which is designed and developed for the old. The shape of the diaphragm is more complex, the use of special pressing process, so that the blasting strength of more than 22kg/cm2. The process of spring manufacturing is improved by multi spring, which is beneficial to the matching of different spring range. The zero function can improve the linear accuracy. Surface treatment using epoxy electrostatic powder spray, with high fastness and corrosion resistance. Has the advantages of uniform, good stability, small size, light weight and so on. Can be equipped with pneumatic, electric - gas valve positioner and air filter and other accessories. Also, it can be equipped with XS type XS light side mounted, top mounted manual operating mechanism.
| 16XC/B11 | 16XC/B22 | 16XC/B23 | 16XC/B34 | 16XC/B45 | 16XC/B56 |
H(mm) | 280 | 280 | 307 | 398 | 467 | 660 |
D(mm) | 280 | 280 | 280 | 360 | 470 | 580 |
Weight(Kg) | 10 | 12 | 16 | 22 | 52 | 125 |
Performance index
|
|
|
| ≤±1 |
|
| ≤1 |
|
Die difference% | ≤0.8 |
|
|
| ±2.5 |
| ±0.1 | ±2.5 |
| ±20 | |
| 20~24 | |
|
| |
Main parts material
|
|
|
|
|
|
| HT200,ZMXA/B-6O ZG250-450 |
|
|
|
|
| 60Si2MnA |
| 2Cr13 |
