Basic Info.
Model NO.
SD100
Thread Position of Valve Rod
Outside Gate Valve
Usage
Drain
Standard
------Webkitformboundarys0cwtmtdpvonw9
Application
Industrial Usage, Water Industrial Usage, Household Usage
Sizes
2" - 48" or Dn 50 - Dn 1200
Pressure Rating
Class150 or Pn6 - Pn16
Materials of Valve Body
Gg25 / A126 B, Ggg40 / A536 60-40-18, etc.
Connection End
Asme B16.5, En 1092, JIS B2220
Face to Face
Mss Sp-81, Asme B16.10, En 558
Transport Package
Wooden Case or Carton
Specification
SGS, GMP
Trademark
U-ideal
Origin
Tianjin, China
HS Code
8481804090
Production Capacity
50000PCS/Year
Product Description
Electric Actuated Knife Gate Valve
Knife gate valves are available in various designs, one-piece body and two-piece bodies, rising stem and non-rising stem, uni-direction and bi-direction structures, resilient and metal seat rings, bonnetless and bolted bonnet designs. For optional designs, deflection cone could divert the flow of abrasive slurries and protect valve seat from abrasion, V port disc and through conduit design are used for throttling service, per customers' requirements.Features of Electric Actuated Knife Gate Valves:
Unidirection design
Replaceable resilient seat
Wafer type cast iron body
Self-cleaning mechanism
Rising stem, outside screw & yoke
Yoke type: Plate or Casting
Electric actuator operation
Applicable Standards of Electric Actuated Knife Gate Valves:
A) Design & Manufacture: MSS SP-61, ASME 16.34
B) Face to Face: MSS SP-81, ASME B16.10, EN 558
C) Connection End: ASME B16.5, EN 1092, JIS B2220
D) Test: MSS SP-81
Sizes: 2" - 48" or DN 50 - DN 1200
Pressure Rating: Class150 or PN6 - PN16
Materials of valve body: GG25 / A126 B, GGG40 / A536 60-40-18, etc.
Operation: Electric actuator
Would you like to get more products information or order it, please call me, or click Inquiry Now to fill in the Form.
It helps you get more informations you need to trade confidently with suppliers.
Related products: Gate Valve Ball Valve Check Valve Globe Valve Butterfly Valve Knife Gate Valve
1. Product name | Knife Gate Valve with Electric Actuator |
| 2. Brand name | GL valve |
| 3. Pressure | PN10&Class150&10K |
| 4. Size | DN50-DN1200&2"-48"&50A-1200A |
| 5. Body material | DI(GGG40)&SS(304,316)(solid solution treatment) |
| 6. Gate material | SS304&SS316(solid solution treatment) |
| 7.Seat material | EPDM&Metal&Viton&NBR |
| 8.Packing material | PTFE& Silicone |
| 9.Support plate | A 36+epoxy plate |
| 10.Operation | Handwheel, bevel gear, DA pneumatic, electric,etc. |
| 11.Packing | Plywood case |
| 12.Payment | T/T, L/C, West union 30% before production, balance before shipment. |
| 13.Quality | Every process is inspected by our QC team |
| 14.Sample | Ready samples are available for inspection reference |
