Basic Info.
Model NO.
VGM0Q2
Pressure
Low Pressure
Flow Direction
Bidirectional
Function
Pneumatic
Usage
Flow Control
Standard
DIN, GB, ANSI, BSW, JIS
Size
1/4"-3/4"
Max. Working Pressure
10bar
Max. Working Temperature
150 Degree C
Operated
Pneumatic
Certificate
3A/CE/FDA
Application Scope
Pharmacy
Transport Package
Standard Exporting Package
Specification
3A/BPE/DIN/ISO/IDF
Trademark
DONJOY
Origin
Wenzhou, Zhejiang, China
HS Code
8481804090
Production Capacity
No Limited
Product Description
Mini Pneumatic Clamp Diaphragm Valve with Stainless Steel Actuator
Donjoy specializes in manufacturing and exporting valve,pump,fitting for over 20 years with good quality and pretty competitive price. Products are with 3A,CE,FDA cetification and production management is according to ISO9001-2008.
Forging body blank is through a piece of stainless steel ingot, in the forging process, along with the high temperature forging provide, through extrusion blank shape change, through the forging after body density higher, the structure is more uniform, no sand hole and other impurities. Then through the processing centre carry on the high precision maching.
Casting body is made by the mould paraffin wax model, paraffin wax model infitration in ceramic, to let the whole body wax mold surface form a layer of strong ceramic. Melt wax mold, then into the melting of the stainless steel solution, after cooling knock off the appearance of ceramic, blank body is made uo.
Casting size is very accurate, the outward appearance is a smooth, clean and tidy.
Donjoy specializes in manufacturing and exporting valve,pump,fitting for over 20 years with good quality and pretty competitive price. Products are with 3A,CE,FDA cetification and production management is according to ISO9001-2008.
Forging body blank is through a piece of stainless steel ingot, in the forging process, along with the high temperature forging provide, through extrusion blank shape change, through the forging after body density higher, the structure is more uniform, no sand hole and other impurities. Then through the processing centre carry on the high precision maching.
Casting body is made by the mould paraffin wax model, paraffin wax model infitration in ceramic, to let the whole body wax mold surface form a layer of strong ceramic. Melt wax mold, then into the melting of the stainless steel solution, after cooling knock off the appearance of ceramic, blank body is made uo.
Casting size is very accurate, the outward appearance is a smooth, clean and tidy.
| Product Name: | Mini Pneumatic Clamp Diaphragm Valve with Ss Actuator |
| Valve Body Material: | SS316L |
| Seal Material: | PTFE + EPDM (double layer) / EPDM / SILICON / FPM (VITON) |
| Max. Working Pressure: | 10Bar |
| Max. Working Temperature: | 150 degree C |
| Availably size: | 1/4"-3/4",DN6-DN15 |
| Availably connection: | Clamp/weld/thread/special connection |
| Availably standard: | 3A/BPE/DIN/ISO/IDF |
| Operated: | Manual,Pneumatic |
| Availably structure: | Straight, tee, U-type, tank bottom |
| Control: | Smart valve positioner / C-TOP control / position sensor |
| Certificate: | 3A/54-02 (1580), PED/97/23/EC, FDA.177.2600 |
| Application scope: | Dairy,food, beverage, pharmacy, cosmetic, etc |
| Packaging Details: | Bubble pack for each valve. Outside packing are carton or plywood cases. Or as per the request of customers. |
| Delivery details: | Usually within 20 days after receiving T/T down payment. |
