Basic Info.
Classification
Air Brake Chamber
Drum Brakes Classification
Brake Chamber
Main Market
South America, North America, Eastern Europe, Mild East, Southeast Asia, Africa, Western Europe, Eastern Asia, Northern Europe, Oceania, Southern Europe, Central America, South Asia
Working Pressure
800kpa
Pushrod Stroke
0 - 76mm
Working Temperature
- 40 ~ +80°c
Surface Treatment
Yellow Zinc Plated, Black Powder Coating
Transport Package
by Sea
Specification
570*240*21mm
Trademark
JZ Brand
Origin
China
HS Code
8708309990
Production Capacity
20000 Per Month
Product Description
we offer OEM~
Click on the link in the description for more information
FAQ:
Q1: How do you guarantee quality?
A: We take quality inspect records from raw material to finished product.
The former department bear 100% responsibility for next process.
Q2: Can you produce if we have samples only?
A: Our technical ability is strong enough to deal with different types of spring.
Sample drawing and customers' interests will be protected well.
Q3: Is it possible to have sample for quality testing?
A: Same or similar sample are available for free.
Q4: What is your MOQ?
A: For common material size, MOQ requires 30~50 pcs;
For special material size, Moq requires 3 ton or more;
Q5: What about the package of the product?
A:The goods will be packed according to your requirements and in well protection before delivery.
Q6: What is your terms of payment?
A: T/T, L/C, Western Union,
You can contact us for any model requirements and Any information on the parts of brake chamber
Product parameters and prices for reference only, the actual situation of the product please consult or call!
| Model | Stroke (mm) | R1 (mm) | R2 (mm) | L1 | L2 | LA (Pushrod thread length) |
| T2024 | 64 | 110 | 88 | 220±5 | 75±5 | 50±4 |
| T2424 | 64 | 116 | 93 | 224±5 | 240±5 | 206±4 |
| T2424EY4 | 64 | 116 | 93 | 224±3 | 240±5 | 245±4 |
| T2424EB1 | 64 | 116 | 93 | 224±5 | 100±5 | 100±4 |
| T2430 | 64 | 163 | 184 | 234±5 | 240±5 | 206±4 |
| T2430MB | 64 | 163 | 184 | 230±5 | 220±5 | 188±4 |
| T2430MB1 | 64 | 163 | 184 | 230±5 | 240±5 | 209±4 |
| T2430EB | 64 | 163 | 184 | 230±5 | 240±5 | 207±4 |
| T2430LEB | 76.2 | 163 | 184 | 265±5 | 240±8 | 206±4 |
| T2430LMB | 76.2 | 163 | 184 | 265±5 | 240±8 | 209±4 |
| T2430LMB1 | 76.2 | 163 | 184 | 265±5 | 240±8 | 209±4 |
| T2430T | 68 | 163 | 184 | 260±5 | 240±5 | 206±4 |
| T2430LS | 68 | 163 | 184 | 260±5 | 240±5 | 206±4 |
| T3030 | 64 | 125 | 105 | 238±5 | 285±5 | 255±4 |
| T3030YB | 64 | 125 | 105 | 238±5 | 285±5 | 255±5 |
| T3030EY2 | 64 | 125 | 105 | 238±5 | 240±5 | 209±5 |
| T3030MB2 | 64 | 125 | 105 | 238±5 | 285±5 | 255±5 |
| T3030MY1 | 64 | 125 | 105 | 238±5 | 220±5 | 188±5 |
| T3030HP | 64 | 125 | 105 | 238±5 | 285±5 | 255±4 |
| T3030MB | 64 | 125 | 105 | 238±5 | 220±5 | 50 |
| T3030MY | 64 | 125 | 105 | 238±5 | 220±5 | 188±4 |
| Model | Pushrod Thread | Air inlet thread | Mounting bolt thread | Mounting Angle | Weight (kg) |
| T2024 | M16×1.5 | M16×1.5 | M16×1.5 | 90° | 7.78 |
| T2424 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 8.1 |
| T2424EY4 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 8.1 |
| T2424EB1 | M16×1.5 | M16×1.5 | M16×1.5 | 90° | 8 |
| T2430 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 90° | 9.2 |
| T2430MB | M16×1.5 | M16×1.5 | M16×1.5 | 0° | 9.2 |
| T2430MB1 | M16×1.5 | M16×1.5 | M16×1.5 | 45° | 9.2 |
| T2430EB1 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.2 |
| T2430LEB | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.5 |
| T2430LMB | M16×1.5 | M16×1.5 | M16×1.5 | 45° | 9.5 |
| T2430LMB1 | M16×1.5 | M16×1.5 | M16×1.5 | 0° | 9.5 |
| T2430T | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.4 |
| T2430LS | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.5 |
| T3030 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.5 |
| T3030YB | M16×1.5 | M16×1.5 | M16×1.5 | 40° | 9.5 |
| T3030EY2 | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.4 |
| T3030MB2 | M16×1.5 | M16×1.5 | M16×1.5 | 45° | 9.5 |
| T3030MY1 | M16×1.5 | M16×1.5 | M16×1.5 | 0° | 9.5 |
| T3030HP | 5/8"-18UNC2A | 3/8"-18NPTF | 5/8"-11UNC2A | 45° | 9.5 |
| T3030MB | M16×1.5 | M16×1.5 | M16×1.5 | 0° | 9.5 |
| T3030MY | M16×1.5 | M16×1.5 | M16×1.5 | 0° | 9.5 |
| Apply To: | TURCK |
| Brand: | ZBJZ |
| Stock Availability: | 3000 |
| Minimum Order QTY: | Negotiable |
| OEM Order Acceptability: | Accept |
| Small order Lead Time: | Negotiable |
| Large Order Lead Time: | Negotiable |
| Quality Warranty: | Three months |
| PACKAGING: | Carton |
| Payment Methods: | TT cash/LC/Western Union |
| Shipment Methods: | Negotiable |
| Port: | Any port |
