Product Description
SS316L Welding Pneumatic Tank Bottom Diaphragm Valve Plastic Actuator
Donjoy for all diaphragm valve conducted a comprehensive technology update in 2015. The upgraded design more in line with GMP, ASME BPE, EHEDG and 3A of the technical requirements of high purity. Especially for handling dead angle reached requirement ≤ 1D to ≤ 3D.
Technical specification:
Donjoy for all diaphragm valve conducted a comprehensive technology update in 2015. The upgraded design more in line with GMP, ASME BPE, EHEDG and 3A of the technical requirements of high purity. Especially for handling dead angle reached requirement ≤ 1D to ≤ 3D.
Technical specification:
| Size | 1"-4", DN25-DN100 |
| Material | Forging body: 1.4404/ 316L/ASME BPE 316L/ 1.4435 BN2 Fe≤0.5 |
| Casting body: 1.4404/316L/ ASTM A351 CF3M | |
| Max. temperature | -30 ºC to 150 ºC (depending on diaphragm) (stainless steel wheel) |
| -30 ºC to 130 ºC(depending on diaphragm) (plastic wheel) | |
| Max. pressure | 10 bar |
| Connection design | welding, clamp, flange, thread, DIN 11864 aseptic flange, clamp, thread |
| Body structure | T type-Tee, L type-Tee, U type-Tee, multiport, tank bottom valve and various body structures |
| Operation way | Manual: plastic and stainless steel handwheel |
| Pneumatic: plastic box stainless steel pneumatic actuator, multifunctional pneumatic actuator. | |
| Control:IL-TOP intelligent positioner, C-TOP intelligent control unit, FKQ-TOP, position feedback device, intelligent electric actuator, manual flow regulator | |
| Long life design | Below 2 bar, maximum life of 800 million times. |
| Application scope | dairy, food, beverage, water processing, wine fine chemicals, pharmaceutical industries etc. |
| Certificate | FDA, USP, 3A, EN, CE |
| Packaging details | standard exporting package or as per the request of customers |
| Delivery details | Usually within 20 days after receiving T/T down payments |
